- Load capacity: 60 kg to 5 tons
Grade accuracy: 0.03% - 0.025%
- Made of stainless steel - Stainless steel
- Altitude analysis and linear calculation
Standard IP67 is suitable for humid environments or routinely cleaned with water and nozzles
PR 76 load cells are specially designed for weighing small and medium tanks (hoppers) and for simple dosing solutions. Due to the suspended tank installation, the loadcell - load cell PR 76 supports the compensatory load that expands the tank's mechanics (such as temperature change).
- PR 76 load cells are designed for industrial environments such as: Fisheries, Pharmaceuticals, Food, Chemicals, Animal feeds, Processing, Agricultural products ...
OIML R60 Standard.
Explosion-proof certificate:
PR 76 (optional)
Ex-Zone 2, 22.
II 3G Ex nA II T6 II 3D Ex tD A22 IP65 T85 ° C.
PR 76 (optional)
Ex-Zone 20, 21.
II 1D IP65 T85 ° C.
